Product feature
The feature of our S11 Carbide Drawing Dies
1. Wear-resisting: strength over 2200N/mm ³ ,do not crack
2. The size area are 20% longer than common mould, which make sure our wire drawing dies can work longer!
3. Using advance cold bushing tech, and interference bushing craft, the wire drawing dies are tightening connect with the steel jacket.
4. Short producing period, we can delivery it to you within 4 days!
Product Introduction
Size information
| D*H | d | L1 | L2 | L3 | L4 | 2a | 2b | r |
| 85*32 | 42.00 | 9.92 | 10.08 | 6.00 | 6.00 | 20 | 40 | 12 |
| 85*32 | 44.70 | 9.92 | 10.08 | 6.00 | 6.00 | 20 | 40 | 12 |
| 90*33 | 47.80 | 10.74 | 10.26 | 6.00 | 6.00 | 20 | 40 | 13 |
| 90*33 | 49.80 | 10.74 | 10.26 | 6.00 | 6.00 | 20 | 40 | 13 |
| 105*35 | 59.50 | 9.92 | 14.08 | 6.00 | 5.00 | 20 | 30 | 12 |
| 110*35 | 59.50 | 5.27 | 14.73 | 6.00 | 5.00 | 14 | 30 | 6 |
| 120*38 | 69.00 | 9.92 | 13.08 | 6.00 | 7.00 | 20 | 30 | 12 |
| 125*40 | 74.00 | 9.92 | 15.08 | 6.00 | 7.00 | 20 | 30 | 12 |
| 130*40 | 79.00 | 9.92 | 15.08 | 6.00 | 7.00 | 20 | 30 | 12 |
Other type we can offer :
S11 Carbide Drawing Dies YG6X information
| Items | Specification |
| YG6X | WC 94% Co 6% |
| Hardness | 91.5HRA |
| Bending Strength | 1560N/mm2 |
| Density | 14.6g/cm3 |
Working shop
500T presser for carbide drawing dies:
HIP Sintering
Carbide Dies With High Wear Resistance
YG8 Standard Drawing Dies
Tungsten Carbide Dies For Mould
Product Packaging
About our factory
Zhuzhou Old Craftsman Precision Alloy Co., Ltd. is focus on tungsten carbide production, precision machining, brazing. Excellent talents, new equipments, the spirit of craftsmen into products!
The carbide drawing dies my company produced is using 100% virgin material with HIP sintering, quality stable from samples to bulk production. Most of the sizes we produced are customized.
Send us drawing as below, we provide you exactly what you need.
