carbide end mill cutter
Application:
It is used for CNC machining center, cnc engraving machine(For cutting Stainless steel，steel or AL
Series Introductions: Ballnose ,Square Head, Corner Radius
4 Flutes, Ballnose
Description | D | Lc | L | d | R | z |
Standard Length | 1.0 | 2 | 50 | 3 | 0.50 | 4 |
1.0~6.0 | 2~14 | 50 | 3~8 | 0.50~3.5 | 4 | |
7.0 | 14 | 60 | 8 | 3.50 | 4 | |
8.0 | 16 | 60 | 8 | 4.00 | 4 | |
9.0 | 18 | 75 | 10 | 4.50 | 4 | |
10.0 | 20 | 75 | 10 | 5.00 | 4 | |
11.0 | 22 | 75 | 12 | 5.50 | 4 |
3 Flutes, Square head
Description | D | Lc | L | d | z |
Standard Length | 1.0~6.0 | 3.0~16 | 50 | 3~6 | 3 |
6.0~8.0 | 16~20 | 60 | 6~8 | 3 | |
8.5~12.0 | 20~30 | 75 | 10~12 | 3 | |
14.0~25.0 | 40~50 | 100 | 14~25 | 3 | |
With Long Flutes Length | 3.0~6.0 | 4.0~6.0 | 75 | 12~21 | 3 |
3.0~12.0 | 4.0~12.0 | 100 | 12~45 | 3 | |
6.0~25.0 | 6.0~25.0 | 150 | 45~75 | 3 | |
With Long Shank Length | 6.0~8.0 | 16~20 | 75 | 6~8 | 3 |
8.0~12.0 | 16~30 | 100 | 6~12 | 3 | |
10.0~12.0 | 25~30 | 150 | 10~12 | 3 | |
With Stub Length | 4.0~6.0 | 2.0~9.0 | 50 | 1~6 | 3 |
8.0 | 10~12 | 60 | 8 | 3 | |
10.0 | 15 | 75 | 10 | 3 | |
12.0 | 18 | 75 | 12 | 3 | |
16 | 24 | 100 | 16 | 3 |
